| Model: |
QR-A8S |
| App: |
V380 Pro |
| System structure: |
Embedded Linux system, ARM chip structure |
| Chip |
AK3918E |
| Resolution: |
2.0MP |
| Sensor Resolution: |
1/2.9"SC2232H、GC2063 1920*1080 |
| Lens |
Fisheye lens (1.35±3%mm) |
| Lens view angle: |
360° |
| View angle: |
Horizontal: 185°/ Vertical:185° |
| Video compression standard: |
H.265/20FPS |
| Minimum illumination: |
0.01Lux@（F2.0，VGC ON),O.Luxwith IR |
| Electronic shutter: |
Auto |
| Backlight compensation: |
Support |
| Noise reduction: |
2D、3D |
| Led quantity: |
3PCS infrared LED |
| Network: |
WIFI wireless transmission (support IEEE802.11b/g/n wireless protocol). |
| Network connection: |
WIFI, AP hotspot |
| Night vision: |
IR-CUT switch Automatic，about 5-8meters (It varies from environment) |
| Audio |
Built-in microphone and speaker, support real-time two-way audio transmission.ADPCM audio compression standard, self-adapt to code stream |
| Network protocol: |
TCP/IP、UDP、RTSP、HTTP
DDNS、DHCP、FTP、NTP |
| Alarm |
1.Motion detection and picture push 2.AI Human intrusion Detection(optional) |
| ONVIF |
Support ONVIF |
| Storage: |
TF Card（Max 128G）；Cloud storage /Cloud disk (optional) |
| Power input: |
5V/1.5A (US and EU plug optional) |
| Work environment: |
Working temperature:-10℃ ~ + 50℃ Working Humidity: ≤95%RH |
