| App |
icsee |
| Model: |
EP27-5M-36X |
| Features |
System security |
Account, password management |
| View by phone |
Support IOS, Android mobile view (iOS 4.3 Android OS 2.3 above),Windows |
| P2P |
support |
| Local Storage |
128GB |
| Monitor Advantage |
Support PC computer monitoring, smartphone multi-pic view. |
| Video |
Compression Format |
H.264/H.264+/H.265X baseline profile |
| Resolution |
5MP(2592*1944) |
| Picture Adjustment |
Contrast, Brightness, Saturation are adjustable. |
| Sensor |
1/2.7" XM550+SC5335 |
| Minimum illumination |
Color: 0. 4Lux, B/W: 0.01Lux |
| SNR |
≥48dB |
| Electronic shutter |
1/50(1/60)s to 1/10,000 s |
| CMOS |
support AWB, AGC, BLC |
| Lens |
4.7-94mm |
| Dome Features |
Address |
0~255 |
| Pan Range |
330 degree |
| Tilt Range |
90 degree |
| Intelligent power off real time memory |
support |
| Intelligent power off real time memory |
support |
| Night vision |
IR-Cut |
Support |
| Night vision |
4PCS IR LED |
| Infrared illumination distance |
Within 100 meters |
| Image |
Maximum image size |
Main stream:2592*1944 |
| Frame rate |
Maximum frame rate: 50Hz: 25fps network frame rate adaptation |
| Function |
AI human detection |
Support |
| Alarm mode |
Siren warning, custom voice playback recording, mobile APP alarm push |
| Two-way voice |
Support |
| Image flip |
Support |
| ONVIF protocol |
Support |
| Digital noise reduction |
Support |
| Audio |
Compression |
G726/G711A |
| Input |
Microphone |
| Output |
Built in speaker |
| Networking |
Online visitor |
Support 5 online visitors simutaneoursly |
| Protocols |
RTSP/FTP/PPPOE/DHCP/DDNS/NTP/UPnP |
| Motion detect |
Support ,send message to the phone |
| Network |
10/100M Base-TX Ethernet, RJ45 Connector |
| Audio I/O |
Support two-way voice |
| WIFI |
WIFI 802.11 b/g/n |
| use environment |
Application environment |
IP66 Waterproof , can use outdoor |
| Rated Voltage |
100V-240V,50-60HZ |
| Work temperature |
–20℃~50℃ |
| Work Humidity |
10%～80% |
| Power |
DC12V; 2A |
| Accessories |
user manual, screws，screwdriver，Waterproof ring bags. |
