Model NO.
|
EP5-QQ-6M-36X
|
|
Camera
|
|
Image Sensor
|
3MP 1/2.8" CMOS
|
|
Solution
|
XM650V200+2236P+2009
|
|
Mini Illumination
|
Color 0.01Lux@F1.2(AGC ON), 0 Lux with IR
Black and White 0.001 Lux @ (F1.2,AGC ON),0 Lux with IR
|
|
Digital Noise Reduction
|
2D/3D DNR
|
|
Image Settings
|
Image Flip
|
|
Function
|
remote monitoring; push message after human detection alarm; image capture
|
|
Lens
|
|
Lens
|
4mm 5.98~93.9 mm ±5%(18X)
|
|
Rotate Range
|
Pan rotation:0~240º, Tilt rotation:0~90º
|
|
Rotation
|
|
Angle
|
Manual control of the rotation adjustment according to the scene to be monitored
|
|
Preset Point
|
Support
|
|
Video
|
|
Image Output
|
Main Stream: 2304*2592@12fps
|
|
Sub-Stream: 640*720@12fps
|
|
Audio
|
|
Audio Compression
|
G.711; Support Two Way Audio
|
|
Al+
|
|
General
|
Human detection, Human tracking, Intrusion alarm, Line crossing detection
|
|
Alarm
|
SD card recording, APP alarm, Sound and light alarm
|
|
APP
|
|
Mobile View
|
Android, IOS ( ICSEE)
|
|
Light
|
|
Warm Light Distance
|
Up to 60 m
|
|
IR Distance
|
Up to 180 m
|
|
LEDS
|
4 PCS IR LEDS +4 PCS LASER LEDS+ 5 PCS White Lights
|
|
Lighting mode
|
Starlight full color; Infrared night vision; Intelligent alert
|
|
General
|
|
Power Supply
|
DC 12V±25％
|
|
Power Connector
|
Φ5.5mm
|
|
Power consumption
|
≤12w
|
|
Operating Conditions
|
(-25℃ ~ 45℃) humidity 95% or less (non-condensing)
|
|
Factory Data Reset
|
Support
|
|
Material
|
Plastic+Metal
|
|
Dimension
|
Product：205*208*328mm
Packing：310*310*440mm
|
