| system |
Model |
Q3-QQ-4M |
| image sensor |
2 1/4" high performance CMOS sensors |
| Operation System |
Embedded LINUX operating system |
| Video Compression |
Smart H.265X |
| APP |
ICSEE (Android and IOS support) |
| Video |
High Definition |
2*2MP |
| Image resolution |
Main code stream: 1920*2160@12fps; Substream: 640*720@12fps |
| Minimum illumination |
0.01 LUX/pro series |
| Lens |
3.6mm(standard) |
| Perspective |
92 ° |
| |
Turn video |
Flip up and down/flip side to side |
| lighting |
Light control mode |
Automatic/light on/off/timer/smart alert |
| Number of lights |
6 red lights +6 white lights |
| PTZ |
PTZ control |
Rotation Angle level :355°; Vertical :90° |
| Turn PTZ |
Flip up and down/flip side to side |
| Audio |
Coding standard |
G.711 |
| Mitou |
support |
| Two-way Speech |
support |
| Record management |
Video file size |
Hd video ≈9.7G/ day SD video ≈2.4G/ day |
| Record Mode |
Manual video recording, dynamic detection video recording, timing video recording, alarm video |
| Video storage |
TF card/cloud |
| storage |
Cloud Storage +TF Local Video recording (256GB Max) |
| Remote playback |
support |
| Image capture |
support |
| Network |
WIFI |
2.4G WIFI 802.11b/g/n |
| Pairing |
WiFi Smartlink distribution network addition, AP hotspot addition, QR code scanning. Bluetooth fast networking |
| Network Protocol |
Support TCP/IP, ONVIF, RTSP |
| extension |
Bluetooth remote control |
support |
| Reset key |
support |
| Human tracking |
support |
| 360degree coordinate positioning |
support |
| power supply |
Power |
AC 100-230V |
| power interfac |
E27 |
| work environment |
Suitable place |
outdoor、Home、shop、School、factory； |
| Installation mode |
hoisting |
| Working Temperature |
-20℃－＋55℃ |
| Working humidity |
10%－90% |
