| system |
Model |
V1 |
| image sensor |
1/3 "low illumination CMOS sensors |
| Operation System |
Embedded LINUX operating system |
| Video Compression |
H.265AI |
| APP |
ICSEE(support for Android and IOS) |
| Video |
High Definition |
3MP |
| Image resolution |
Main stream: 2304*1296@12fps; Substream: 800*448@12fps |
| Minimum illumination |
Color: 0.01Lux @(F1.2,AGC ON); 0 Lux with IR;
Black and white: 0.001 Lux @ (F1.2,AGC ON),0 Lux with IR |
| Lens |
3.6mm(standard) |
| Perspective |
92 ° |
| |
Turn video |
Flip up and down/flip left and right |
| lighting |
Light control mode |
Starlight full color/Intelligent warning/infrared night vision |
| Number of lights |
4 red lights +4 white lights |
| PTZ |
PTZ control |
Rotation Angle level :355°; Vertical :60° |
| Turn PTZ |
Flip up and down/flip left and right |
| Audio |
Coding standard |
G.711 |
| Mitou |
support |
| Two-way Speech |
support |
| Record management |
Video file size |
Hd video≈9.7G/day, SD video≈2.4G/day |
| Record Mode |
All-weather video, dynamic detection video, alarm video |
| Video storage |
TF card/Cloud |
| storage |
Cloud storage +TF local video (Max 128GB) |
| Remote playback |
support |
| Image capture |
support |
| Network |
Wireless network |
2.4G WIFI 802.11b/g/n |
| Distribution network |
WiFi Smartlink distribution network add, AP hotspot add, QR code scan |
| Network protocol |
TCP/IP, RTSP, ONVIF |
| Extended function |
Display screen |
2.8-inch display |
| Reset key |
support |
| Humanoid tracking |
support |
| 360 degree positioning |
support |
| power supply |
Power |
DC 5V 1.6A |
| power interfac |
Micro Type-C |
| work environment |
Suitable place |
Homes, shops, supermarkets, factories and other places; |
| Installation mode |
lay flat |
| Working Temperature |
- 20 ℃ - + 55 ℃ |
| Working humidity |
10% - 90%. |
