| Model |
EP8B |
| App |
icsee |
| support system |
Support IOS, Android mobile view (iOS 4.3 Android OS 2.3 above),Windows, |
| Storage |
Support cloud /TF Card stroage (Max 128GB) |
| Monitor Advantage |
Support PC computer monitoring, smartphone multi-pic view. |
| View Angel |
80 degree |
| Compression Format |
H.265 |
| Resolution |
1920*1080 |
| Sensor |
1/2.7" XM530+335E |
| Minimum illumination |
Color: 0. 4Lux, B/W: 0.01Lux |
| SNR |
≥48dB |
| Electronic shutter |
1/50(1/60)s to 1/10,000 s |
| Lens |
3.6mm |
| Pan-tilt |
H:350degree, V: 90 degree |
| IR CUT |
IR-Cut switch day and night auto |
| Night vision |
4 pcs IR LED + 4pcs Warm white LED , support infrared night vision/ full color night vision/ smart night vision |
| Infrared illumination distance |
within 30 meters |
| Maximum image size |
Main stream: 1920*1080; |
| Frame rate |
Maximum frame rate: 50Hz: 25fps network frame rate adaptation |
| Alert function |
Intelligent double light humanoid recognition alarm / mix line, area, two-way flow detection |
| Human Tracking |
support |
| Alarm mode |
Siren warning, custom voice playback recording, mobile APP alarm push |
| Two-way voice |
support |
| ONVIF protocol |
Support |
| Digital noise reduction |
2D/3D digital noise reduction |
| Motion detect |
Support ,send message to the phone |
| Network Connection: |
AP hotspot , WIFI WIFI 802.11 b/g/n, 10/100M Base-TX Ethernet, RJ45 Connector |
| Work temperature |
–20℃~50℃ |
| Work Humidity |
10%～80% |
| Power |
DC12V; 2A (price not including power supply) |
| Accessories |
user manual, screws，screwdriver，Waterproof connector bags. |
