| Model Number |
VC9-W |
| DSP |
AK V300 |
| Operating system |
Android, IOS |
| APP: |
V380 PRO |
| Sensor: |
GC2063 Gcoreinc image sensor |
| Video compressed format: |
H.264+/H.265 |
| Resolution: |
1920*1080 |
| network |
2.4G WIFI |
| Detection method: |
PIR + Radar dual induction detection |
| Detection distance: |
0~12M |
| Detection angle: |
120° |
| Alarm method: |
Double induction confirmation and push alarm information mobilephone |
| Pan-tilt: |
Horizontal: 355 °, vertical: 90° |
| Rotate speed |
Horizontal 55°/seconds, vertical 40°/seconds |
| Full color night vision: |
minimum illumination 0.00001LUX |
| IR Leds |
8pcs Dual Core LED |
| Infrared Led: |
Infrared LED distance: 20M ,effective distance :8M |
| White Led: |
White LED distance: 20M, effective distance :8M |
| Built-in speaker: |
3W |
| Built-in microphone: |
Audio pick-up about 20M |
| Lens: |
fixed-focus 4mm |
| Angle: |
80° |
| Cloud storage: |
Cloud Storage (Alarm video ) |
| Local storage: |
TF card（Max 128G） |
| power supply mode : |
solar panel + 3.7V 18650 battery |
| Solar panel power: |
8W |
| Battery capacity |
Built-in 8000mah battery |
| Operating power |
daytime: 350-400ma,Night time:500-550ma |
| Standby power |
5 mAh |
| work environment: |
IP66 Waterproof,can use indoor and outdoor |
| Working temperature: |
-30°~+50° |
| Working humidity: |
0%~80%RH |
