Model: |
C6S-H |
APP: |
V380 Pro |
System structure: |
Embedded Linux system, ARM chip structure |
Chip: |
AK3918E V330 |
Resolution: |
3.0MP |
Sensor Resolution: |
1/2.9″SC2063 |
Lens |
4MM |
View angle: |
80° |
Pan-tilt: |
Rotates Horizontal:355° Vertical:90° |
Preset point quantity: |
6 |
Video compression standard: |
H.265/20FPS |
Video format: |
PAL |
Minimum illumination: |
0.01Lux@(F2.0,VGC ON),O.Luxwith IR |
Electronic shutter: |
Auto |
Backlight compensation: |
Support |
Noise reduction: |
2D、3D |
Led quantity: |
4pcs White Led + 2pcs Infrared LED |
Connection method: |
WIFI, AP hotspot , RJ45 Network port |
Network: |
WIFI wireless transmission (support IEEE802.11b/g/n wireless protocol). |
Night vision |
IR-CUT switch Automatic,about 5-8meters (It varies from environment)
White Led can be remote control via APP:①Turn ON ②Turn OFF ③ Auto
(In automatic mode, the infrared light will be turned ON after the IR-cut switch to night vision automatically , it can intelligently detected human body, and Turn ON/OFF the White light intelligently ) |
Audio: |
Built-in microphone and speaker, support two-way audio and real-time transmission.
ADPCM audio compression standard, self-adapt to code stream |
Network protocol: |
TCP/IP、UDP、HTTP、 DDNS、DHCP、FTP、NTP |
Alarm: |
①Motion detection and picture push ②AI Human intrusion Detection (optional) |
ONVIF |
Support ONVIF |
Storage: |
TF Card(Max 128G);Cloud storage /Cloud disk (optional) |
Power input: |
12V/2A |
Work environment: |
Working temperature:-10℃ ~ + 50℃ Working Humidity: ≤95%RH |
