| Model Number |
VCS02-4G |
| DSP |
AK KM01N |
| Operating system |
Android, IOS |
| APP: |
V380 PRO |
| Sensor: |
1/2.9" Progressive Scan CMOS（GC3003*2） |
| Video compressed format: |
H.265 |
| Resolution: |
2560*1296P |
| 4G Network : |
4G-BAND B1/3/5/8/38/39/40/41 |
| Detection method: |
PIR + Radar dual induction detection |
| Detection distance: |
0~12M |
| Detection angle: |
120° |
| Alarm method: |
Double induction confirmation and push alarm information mobilephone |
| Pan-tilt: |
Horizontal: 355 °, vertical: 90° |
| Rotate speed |
Horizontal 55°/seconds, vertical 40°/seconds |
| Full color night vision: |
minimum illumination 0.00001LUX |
| Infrared Led: |
Infrared LED distance: 30M ,effective distance :10M |
| White Led: |
White LED distance: 30M, effective distance :10M |
| Built-in speaker: |
3W |
| Built-in microphone: |
Audio pick-up eara about 20M |
| Lens: |
fixed-focus 4mm+4mm |
| Angle: |
80° |
| Cloud storage: |
Cloud Storage (Alarm video ) |
| Local storage: |
TF card（Max 128G） |
| power supply mode : |
solar panel + 3.7V 18650 battery |
| Solar panel power: |
10W |
| Battery capacity |
Built-in 4pcs 2000ma 18650 battery |
| Operating power |
daytime: 350-400ma,Night time:500-550ma |
| Standby power |
5 mA |
| work environment: |
IP66 Waterproof,can use indoor and outdoor |
| Working temperature: |
-30°~+50° |
| Working humidity: |
0%~80%RH |
